Description
4 Channel | Camera Compatibility Analog/IP/AHD 4K/HDCVI 4K/HD-TVI/TurboHD 4K | SATA | 4xAudio-In | 1xAudio-Out | 1xUSB 2.0 | 1xUSB 3.0 | 1xRJ45 | 1xRS-485 | DC 12V/2A
Short Description
https://ecom.elkogroup.com/Catalog/Product/1437445
Downloadable Files
DVR 4CH HDCVI PENTABRID/XVR7104H-4K-I3 DAHUA
| Description: XVR7104H-4K-I34CH<br/> Penta-brid 4K Mini 1U 1HDD WizSense Digital Video Recorder > 2-channel QuickPick 2.0 for analog channels which improves the efficiency of target retrieval.<br/> > 1-channel Privacy Protection for analog channels which supports masking and restoring human faces that are detected in real time.<br/> > 4-channel SMD Plus for analog channels or 8-channel SMD by camera which allows the device to trigger accurate alarms for humans and vehicles.<br/> > 4-channel perimeter protection for analog channels which supports tripwire and intrusion detection powered by AI.<br/> > 2-channel face recognition for analog channels which supports face comparison.<br/> > 4-channel AI Coding saves on storage and bandwidth while maintaining the details of targets in videos.<br/> > Supports HDCVI, AHD, TVI, CVBS and IP video input.<br/> > Supports up to 8-channel IP camera input and each channel can be up to 8 MP. The incoming bandwidth reaches 128 Mbps.<br/> > Smart H.265+ and H.265 dual-stream video compression. |
| Vendor Homepage: www.dahuasecurity.com/products/All-Products/HDCVI-Recorders/4K-series/XVR7104H-4K-I3 |
| RJ45: 1 |
| Shipping Box Depth: 37.5 |
| Shipping Box Height: 11.5 |
| Shipping Box Weight: 1.86 |
| Shipping Box Width: 31 |
| Unit Box Width: 0.31 |
| Unit Box Length: 0.375 |
| Unit Box Height: 0.115 |
| Full Description Line: 4 Channel|Camera Compatibility Analog/IP/AHD 4K/HDCVI 4K/HD-TVI/TurboHD 4K|SATA|4xAudio-In|1xAudio-Out|1xUSB 2.0|1xUSB 3.0|1xRJ45|1xRS-485|DC 12V/2A |
| Category Code: STD |
| Model: XVR7104H-4K-I3 |
| Dimensions: 325.0 × 254.3 × 55.0 mm |
| Units per Shipping Box: 1 |
| Unit Calculated Volume: 0.01337 |
| Product Net Weight: 1 |
| Unit Calculated Weight: 1.86 |
| USB 2.0: 1 |
| Power supply requirements: DC 12V/2A |
| USB 3.0: 1 |
| SATA: Yes |
| Audio-In: 4 |
| Audio-Out: 1 |
| RS-485: 1 |
| Camera Compatibility: AHD 4K/Analog/HDCVI 4K/HD-TVI/TurboHD 4K/IP |
| DVR type: 4 Channel |
Warranty:
36 months
Specifications
Description:
XVR7104H-4K-I34CH<br/>
Penta-brid 4K Mini 1U 1HDD WizSense Digital Video Recorder
> 2-channel QuickPick 2.0 for analog channels which improves the efficiency of target retrieval.<br/>
> 1-channel Privacy Protection for analog channels which supports masking and restoring human faces that are detected in real time.<br/>
> 4-channel SMD Plus for analog channels or 8-channel SMD by camera which allows the device to trigger accurate alarms for humans and vehicles.<br/>
> 4-channel perimeter protection for analog channels which supports tripwire and intrusion detection powered by AI.<br/>
> 2-channel face recognition for analog channels which supports face comparison.<br/>
> 4-channel AI Coding saves on storage and bandwidth while maintaining the details of targets in videos.<br/>
> Supports HDCVI, AHD, TVI, CVBS and IP video input.<br/>
> Supports up to 8-channel IP camera input and each channel can be up to 8 MP. The incoming bandwidth reaches 128 Mbps.<br/>
> Smart H.265+ and H.265 dual-stream video compression.
Vendor Homepage:
www.dahuasecurity.com/products/All-Products/HDCVI-Recorders/4K-series/XVR7104H-4K-I3
RJ45:
1
Shipping Box Depth:
37.5
Shipping Box Height:
11.5
Shipping Box Weight:
1.86
Shipping Box Width:
31
Unit Box Width:
0.31
Unit Box Length:
0.375
Unit Box Height:
0.115
Full Description Line:
4 Channel|Camera Compatibility Analog/IP/AHD 4K/HDCVI 4K/HD-TVI/TurboHD 4K|SATA|4xAudio-In|1xAudio-Out|1xUSB 2.0|1xUSB 3.0|1xRJ45|1xRS-485|DC 12V/2A
Category Code:
STD
Model:
XVR7104H-4K-I3
Dimensions:
325.0 × 254.3 × 55.0 mm
Units per Shipping Box:
1
Unit Calculated Volume:
0.01337
Product Net Weight:
1
Unit Calculated Weight:
1.86
USB 2.0:
1
Power supply requirements:
DC 12V/2A
USB 3.0:
1
SATA:
Yes
Audio-In:
4
Audio-Out:
1
RS-485:
1
Camera Compatibility:
AHD 4K/Analog/HDCVI 4K/HD-TVI/TurboHD 4K/IP
DVR type:
4 Channel
