Description
AMD B850 | SAM5 | ATX | DDR5 | 8200/8000/7950/7900/7800/7600/7400/7200/7000/6800/6600/6400/6200/6000/5800/5600/5200/4800 MHz | Memory slots 4 | 4xPCI-Express 16x | 3xM.2 | 1xHDMI | 1xDisplayPort | 1xAudio-In | 1xAudio-Out | 1xMicrophone | 4xUSB 2.0 | 4xUSB 3.2 | 1xUSB-C | 1xPS/2 | 1xRJ45 | SATA | USB-C | USB 2.0 | USB 3.2 | Bluetooth | WiFi | SATA 3.0 | Video Depending on CPU | Audio | LAN Gigabit | RAID SATA 0, 1, 10 | TPM Header
Short Description
https://ecom.elkogroup.com/Catalog/Product/1430751
Downloadable Files
Mainboard|GIGABYTE|AMD B850|SAM5|ATX|Memory DDR5|Memory slots 4|4xPCI-Express 16x|3xM.2|1xHDMI|1xDisplayPort|1xAudio-In|1xAudio-Out|1xMicrophone|4xUSB 2.0|4xUSB 3.2|1xUSB-C|1xPS/2|1xRJ45|B850GAMINGWF6
| Description: GIGABYTE B850 GAMING WIFI6<br/> <br/> X3D Turbo Mode<br/> Unleash new era gaming performance<br/> <br/> DDR5 OC<br/> up to 8200MT/s<br/> <br/> AMD Socket AM5<br/> Supports AMD Ryzen 9000 / 8000 / 7000 Series Processors<br/> <br/> Digital 6+2+2 phases<br/> VRM solution<br/> <br/> Dual Channel DDR5<br/> 4*DIMMs with AMD EXPO™Memory Module Support<br/> <br/> WIFI EZ-Plug<br/> Quick and easy design for Wi-Fi antenna installation<br/> <br/> PCIe EZ-Latch Plus<br/> PCIe slots with Quick Release Design<br/> <br/> Friendly UI<br/> Multi-Theme, AIO Fan Control, and Q-Flash Auto Scan in BIOS and SW.<br/> <br/> Ultra-Fast Storage<br/> 3*M.2 slots, including PCIe 5.0x4 slot<br/> <br/> Efficient Thermal<br/> VRM Thermal Armor Advanced<br/> <br/> Fast Networking<br/> GbE LAN & Wi-Fi 6 802.11ax<br/> <br/> Extended Connectivity<br/> HDMI, Displaypor |
| Vendor Homepage: www.gigabyte.com/Motherboard/B850-GAMING-WIFI6#kf |
| RJ45: 1 |
| Shipping Box Depth: 58.7 |
| Shipping Box Height: 38.5 |
| Shipping Box Weight: 14.1 |
| Shipping Box Width: 36.5 |
| Unit Box Width: 0.277 |
| Unit Box Length: 0.34 |
| Unit Box Height: 0.082 |
| Full Description Line: AMD B850|SAM5|ATX|DDR5|8200/8000/7950/7900/7800/7600/7400/7200/7000/6800/6600/6400/6200/6000/5800/5600/5200/4800 MHz|Memory slots 4|4xPCI-Express 16x|3xM.2|1xHDMI|1xDisplayPort|1xAudio-In|1xAudio-Out|1xMicrophone|4xUSB 2.0|4xUSB 3.2|1xUSB-C|1xPS/2|1xRJ45|SATA|USB-C|USB 2.0|USB 3.2|Bluetooth|WiFi|SATA 3.0|Video Depending on CPU|Audio|LAN Gigabit|RAID SATA 0, 1, 10|TPM Header |
| Category Code: MBA |
| Model: B850 GAMING WIFI6 |
| Units per Shipping Box: 8 |
| Unit Calculated Volume: 0.01031 |
| Product Net Weight: 1.3 |
| Unit Calculated Weight: 1.76 |
| Form Factor: ATX |
| Socket: SAM5 |
| SATA 3.0: Yes |
| Microphone: 1 |
| Memory type: DDR5 |
| Frequency speed: 4800/5200/5600/5800/6000/6200/6400/6600/6800/7000/7200/7400/7600/7800/7900/7950/8000/8200 |
| Bluetooth: Yes |
| SATA: Yes |
| HDMI: 1 |
| Audio-In: 1 |
| Audio-Out: 1 |
| Integrated LAN: Gigabit |
| DisplayPort: 1 |
| WiFi: Yes |
| PS/2: 1 |
| M.2: 3 |
| Chipset: AMD B850 |
| Memory slots: 4 |
| Integrated video: Depending on CPU |
| Integrated audio: Yes |
| RAID: SATA 0, 1, 10 |
| TPM: Header |
| PCI-Express 16x: 4 |
Warranty:
36 months
Specifications
Description:
GIGABYTE B850 GAMING WIFI6<br/>
<br/>
X3D Turbo Mode<br/>
Unleash new era gaming performance<br/>
<br/>
DDR5 OC<br/>
up to 8200MT/s<br/>
<br/>
AMD Socket AM5<br/>
Supports AMD Ryzen 9000 / 8000 / 7000 Series Processors<br/>
<br/>
Digital 6+2+2 phases<br/>
VRM solution<br/>
<br/>
Dual Channel DDR5<br/>
4*DIMMs with AMD EXPO™Memory Module Support<br/>
<br/>
WIFI EZ-Plug<br/>
Quick and easy design for Wi-Fi antenna installation<br/>
<br/>
PCIe EZ-Latch Plus<br/>
PCIe slots with Quick Release Design<br/>
<br/>
Friendly UI<br/>
Multi-Theme, AIO Fan Control, and Q-Flash Auto Scan in BIOS and SW.<br/>
<br/>
Ultra-Fast Storage<br/>
3*M.2 slots, including PCIe 5.0x4 slot<br/>
<br/>
Efficient Thermal<br/>
VRM Thermal Armor Advanced<br/>
<br/>
Fast Networking<br/>
GbE LAN & Wi-Fi 6 802.11ax<br/>
<br/>
Extended Connectivity<br/>
HDMI, Displaypor
Vendor Homepage:
www.gigabyte.com/Motherboard/B850-GAMING-WIFI6#kf
RJ45:
1
Shipping Box Depth:
58.7
Shipping Box Height:
38.5
Shipping Box Weight:
14.1
Shipping Box Width:
36.5
Unit Box Width:
0.277
Unit Box Length:
0.34
Unit Box Height:
0.082
Full Description Line:
AMD B850|SAM5|ATX|DDR5|8200/8000/7950/7900/7800/7600/7400/7200/7000/6800/6600/6400/6200/6000/5800/5600/5200/4800 MHz|Memory slots 4|4xPCI-Express 16x|3xM.2|1xHDMI|1xDisplayPort|1xAudio-In|1xAudio-Out|1xMicrophone|4xUSB 2.0|4xUSB 3.2|1xUSB-C|1xPS/2|1xRJ45|SATA|USB-C|USB 2.0|USB 3.2|Bluetooth|WiFi|SATA 3.0|Video Depending on CPU|Audio|LAN Gigabit|RAID SATA 0, 1, 10|TPM Header
Category Code:
MBA
Model:
B850 GAMING WIFI6
Units per Shipping Box:
8
Unit Calculated Volume:
0.01031
Product Net Weight:
1.3
Unit Calculated Weight:
1.76
USB 2.0:
Yes,
4
Form Factor:
ATX
USB 3.2:
Yes,
4
Socket:
SAM5
USB-C:
1,
Yes
SATA 3.0:
Yes
Microphone:
1
Memory type:
DDR5
Frequency speed:
4800/5200/5600/5800/6000/6200/6400/6600/6800/7000/7200/7400/7600/7800/7900/7950/8000/8200
Bluetooth:
Yes
SATA:
Yes
HDMI:
1
Audio-In:
1
Audio-Out:
1
Integrated LAN:
Gigabit
DisplayPort:
1
WiFi:
Yes
PS/2:
1
M.2:
3
Chipset:
AMD B850
Memory slots:
4
Integrated video:
Depending on CPU
Integrated audio:
Yes
RAID:
SATA 0, 1, 10
TPM:
Header
PCI-Express 16x:
4
